Validation Data Gallery

Filter: AllWBIPIHCIF/ICCFC (Intra)

WB analysis using 19132-1-AP
Various lysates were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC Delta antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.
WB analysis using 19132-1-AP
Non-treated and PMA treated THP-1 cells were subjected to SDS PAGE followed by western blot with 29564-1-AP (Phospho-PKC delta (Thr507) antibody) at dilution of 1:500 incubated at room temperature for 1.5 hours. The membrane was stripped and re-blotted with PKC Delta antibody (19132-1-AP) subsequently.
WB analysis of mouse colon using 19132-1-AP
mouse colon tissue were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC delta antibody at dilution of 1:600 incubated at room temperature for 1.5 hours.
WB analysis of HT-1080 using 19132-1-AP
HT-1080 cells were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC delta antibody) at dilution of 1:500 incubated at room temperature for 1.5 hours.
WB analysis of A431 using 19132-1-AP
A431 cells were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC delta antibody) at dilution of 1:400 incubated at room temperature for 1.5 hours.
WB analysis of Jurkat using 19132-1-AP
Jurkat cells were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC delta antibody) at dilution of 1:400 incubated at room temperature for 1.5 hours.
WB analysis of MCF-7 using 19132-1-AP
MCF7 cells were subjected to SDS PAGE followed by western blot with 19132-1-AP (PKC delta antibody) at dilution of 1:300 incubated at room temperature for 1.5 hours.
IP experiment of A431 using 19132-1-AP
IP result of anti-PKC Delta (IP:19132-1-AP, 4ug; Detection:19132-1-AP 1:800) with A431 cells lysate 2640 ug.
IP experiment of A431 using 19132-1-AP
IP result of anti-PKC Delta (IP:19132-1-AP, 4ug; Detection:19132-1-AP 1:500) with A431 cells lysate 2000ug.
IHC staining of mouse liver using 19132-1-AP
Immunohistochemical analysis of paraffin-embedded mouse liver tissue slide using 19132-1-AP (PKC Delta antibody) at dilution of 1:200 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IHC staining of mouse liver using 19132-1-AP
Immunohistochemical analysis of paraffin-embedded mouse liver tissue slide using 19132-1-AP (PKC Delta antibody) at dilution of 1:200 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IHC staining of human colon using 19132-1-AP
Immunohistochemical analysis of paraffin-embedded human colon using 19132-1-AP (PKC delta antibody) at dilution of 1:100 (under 10x lens).
IHC staining of human colon using 19132-1-AP
Immunohistochemical analysis of paraffin-embedded human colon using 19132-1-AP (PKC delta antibody) at dilution of 1:100 (under 40x lens).
IF Staining of U2OS using 19132-1-AP
Immunofluorescent analysis of (4% PFA) fixed U2OS cells using PKC Delta antibody (19132-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red).
IF Staining of U-251 using 19132-1-AP
Immunofluorescent analysis of (4% PFA) fixed U-251 cells using PKC Delta antibody (19132-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red).
IF Staining of HeLa using 19132-1-AP
Immunofluorescent analysis of (4% PFA) fixed HeLa cells using PKC Delta antibody (19132-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red).
IF Staining of A431 using 19132-1-AP
Immunofluorescent analysis of (4% PFA) fixed A431 cells using PKC Delta antibody (19132-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L), CL594-Phalloidin (red).
FC experiment of HeLa using 19132-1-AP
1X10^6 HeLa cells were intracellularly stained with 0.4 ug Anti-Human PKC Delta (19132-1-AP) and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Control Antibody. Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

Featured Product
KD/KO Validated

PKC Delta Polyclonal antibody

PKC Delta Polyclonal Antibody for WB, IHC, IF/ICC, FC (Intra), IP, ELISA

Cat No. 19132-1-AP

Publications(8)

Host / Isotype

Rabbit / IgG

Reactivity

human, mouse, rat

Applications

WB, IHC, IF/ICC, FC (Intra), IP, CoIP, ELISA

Synonyms

PRKCD, EC:2.7.10.2, EC:2.7.11.13, MAY1, nPKC-delta

Formulation: PBS and Azide

PBS and Azide

Conjugate: Unconjugated

Unconjugated

Size/Concentration:

-/ -

ご購入について

国内販売は「コスモ・バイオ株式会社」を通じて行っております。お見積り・ご注文はお近くの販売代理店へご連絡ください。

国内在庫・納期について

約2万点のプロテインテック製品をコスモバイオ社物流センター（国内）に在庫しています。国内在庫の有無はコスモバイオ社ホームページの「品番検索」でカタログ番号を検索して確認できます。

保証・サポートについて

テクニカルサポートまたはご購入後1年間の交換／補填対応を承ります。詳細はこちらをご覧ください。

Overview

Tested Applications
Product Information
Publications (8)
Protocols

データシート［PDF］を印刷

MSDS

Tested Applications

Positive WB detected in	A431 cells, Jurkat cells, MCF-7 cells, HT-1080 cells, mouse colon tissue, HUVEC cells
Positive IP detected in	A431 cells
Positive IHC detected in	mouse liver tissue, human colon tissue **Note: suggested antigen retrieval with TE buffer pH 9.0; () Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0***
Positive IF/ICC detected in	U2OS cells, U-251 cells, HeLa cells, A431 cells
Positive FC (Intra) detected in	HeLa cells

Recommended dilution

Application	Dilution
Western Blot (WB)	WB : 1:500-1:2000
Immunoprecipitation (IP)	IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
Immunohistochemistry (IHC)	IHC : 1:50-1:500
Immunofluorescence (IF)/ICC	IF/ICC : 1:200-1:800
Flow Cytometry (FC) (INTRA)	FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Published Applications

KD/KO	See 1 publications below
WB	See 7 publications below
IHC	See 1 publications below
IF	See 1 publications below
IP	See 1 publications below
CoIP	See 1 publications below

Product Information

19132-1-AP targets PKC Delta in WB, IHC, IF/ICC, FC (Intra), IP, CoIP, ELISA applications and shows reactivity with human, mouse, rat samples.

Tested Reactivity	human, mouse, rat
Cited Reactivity	human, mouse, rat
Host / Isotype	Rabbit / IgG
Class	Polyclonal
Type	Antibody
Immunogen	CatNo: Ag5631 Product name: Recombinant human PRKCD protein Source: e coli.-derived, PET28a Tag: 6*His Domain: 326-676 aa of BC043350 Sequence: DMQDNSGTYGKIWEGSSKCNINNFIFHKVLGKGSFGKVLLGELKGRGEYFAIKALKKDVVLIDDDVECTMVEKRVLTLAAENPFLTHLICTFQTKDHLFFVMEFLNGGDLMYHIQDKGRFELYRATFYAAEIMCGLQFLHSKGIIYRDLKLDNVLLDRDGHIKIADFGMCKENIFGESRASTFCGTPDYIAPEILQGLKYTFSVDWWSFGVLLYEMLIGQSPFHGDDEDELFESIRVDTPHYPRWITKESKDILEKLFEREPTKRLGVTGNIKIHPFFKTINWTLLEKRRLEPPFRPKVKSPRDYSNFDQEFLNEKARLSYSDKNLIDSMDQSAFAGFSFVNPKFEHLLED 相同性解析による交差性が予測される生物種
Full Name	protein kinase C, delta
Calculated molecular weight	78 kDa
Observed molecular weight	70 kDa
GenBank accession number	BC043350
Gene Symbol	PKC Delta
Gene ID (NCBI)	5580
RRID	AB_10637263
Conjugate	Unconjugated
Form
Form	Liquid
Purification Method	Antigen affinity purification
UNIPROT ID	Q05655
Storage Buffer	PBS with 0.02% sodium azide and 50% glycerol{{ptg:BufferTemp}}7.3
Storage Conditions	Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage.

Protocols

Product Specific Protocols
WB protocol for PKC Delta antibody 19132-1-AP	Download protocol
IHC protocol for PKC Delta antibody 19132-1-AP	Download protocol
IF protocol for PKC Delta antibody 19132-1-AP	Download protocol
IP protocol for PKC Delta antibody 19132-1-AP	Download protocol

Standard Protocols
Click here to view our Standard Protocols

Publications

Species	Application	Title
human	WB,IP,IHC,IF,CoIP	Oncogene TRIM69 suppressed the anoikis resistance and metastasis of gastric cancer through ubiquitin‒proteasome-mediated degradation of PRKCD Authors - Linqing Sun View Article
mouse	WB	Virol Sin Rottlerin plays an antiviral role at early and late steps of Zika virus infection Authors - Shili Zhou KD Validated View Article
rat	WB	Food Chem Toxicol G-Rh4 improves pancreatic β-cells dysfunction in vivo and in vitro by increased expression of Nrf2 and its target genes. Authors - Yao Liu View Article
	WB	Fish Shellfish Immunol In vivo study of a novel protein kinase C that mediates immunocompetence and catecholamine biosynthesis in hemocytes of Litopenaeus vannamei by using its potential competitive inhibitor, bisindolylmaleimide I. Authors - Zhong-Wen Chang View Article
mouse	WB	iScience Induction of Inflammatory Macrophages in the Gut and Extra-Gut Tissues by Colitis-Mediated Escherichia coli. Authors - Houbao Qi View Article
mouse	WB	Neurochem Int Protein kinase C-mediated impairment of glutamine outward transport and SN1 transporter distribution by ammonia in mouse cortical astrocytes. Authors - Katarzyna Dąbrowska View Article
