Validation Data Gallery

Filter: AllWBIPIHCIF/ICC

WB analysis using 22026-1-AP
mouse testis lysates were subjected to SDS PAGE followed by western blot with 22026-1-AP (NPHP3 antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.
WB analysis of mouse liver using 22026-1-AP
mouse liver tissue were subjected to SDS PAGE followed by western blot with 22026-1-AP (NPHP3 antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.
WB analysis of HEK-293 using 22026-1-AP
HEK-293 cells were subjected to SDS PAGE followed by western blot with 22026-1-AP (NPHP3 antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.
WB analysis of human testis using 22026-1-AP
human testis tissue were subjected to SDS PAGE followed by western blot with 22026-1-AP (NPHP3 antibody) at dilution of 1:500 incubated at room temperature for 1.5 hours.
WB analysis of HepG2 using 22026-1-AP
HepG2 cells were subjected to SDS PAGE followed by western blot with 22026-1-AP (NPHP3 antibody) at dilution of 1:500 incubated at room temperature for 1.5 hours.
IP experiment of mouse testis using 22026-1-AP
IP result of anti-NPHP3 (IP:22026-1-AP, 4ug; Detection:22026-1-AP 1:1000) with mouse testis tissue lysate 4000ug.
IHC staining of human heart using 22026-1-AP
Immunohistochemical analysis of paraffin-embedded human heart tissue slide using 22026-1-AP (NPHP3 Antibody) at dilution of 1:50 (under 40x lens).
IHC staining of human heart using 22026-1-AP
Immunohistochemical analysis of paraffin-embedded human heart tissue slide using 22026-1-AP (NPHP3 Antibody) at dilution of 1:50 (under 10x lens).
IF Staining of hTERT-RPE1 cells using 22026-1-AP
IF result (the base and the lower half of cilia stain) of anti-NPHP3 (22026-1-AP, 1:50) with serum-starved hTERT-RPE1 (MeOH fixed) by Dr. Moshe Kim.
IF Staining of MDCK using 22026-1-AP
Immunofluorescent analysis of (-20°C Ethanol) fixed MDCK cells using 22026-1-AP (NPHP3 antibody) at dilution of 1:50 and Alexa Fluor 488-conjugated Goat Anti-Rabbit IgG(H+L).

NPHP3 Polyclonal antibody

NPHP3 Polyclonal Antibody for WB, IHC, IF/ICC, IP, ELISA

Cat No. 22026-1-AP

Publications(8)

Host / Isotype

Rabbit / IgG

Reactivity

human, mouse, rat, canine

Applications

WB, IHC, IF/ICC, IP, ELISA

Synonyms

Nephrocystin-3, Nephrocystin 3, MKS7, KIAA2000

Formulation: PBS, Azide, Glycerol

PBS, Azide, Glycerol

Conjugate: Unconjugated

Unconjugated

Size/Concentration:

-/ -

ご購入について

国内販売は「コスモ・バイオ株式会社」を通じて行っております。お見積り・ご注文はお近くの販売代理店へご連絡ください。

国内在庫・納期について

約2万点のプロテインテック製品をコスモバイオ社物流センター（国内）に在庫しています。国内在庫の有無はコスモバイオ社ホームページの「品番検索」でカタログ番号を検索して確認できます。

保証・サポートについて

テクニカルサポートまたはご購入後1年間の交換／補填対応を承ります。詳細はこちらをご覧ください。

Overview

Tested Applications
Product Information
Publications (8)
Protocols

データシート［PDF］を印刷

MSDS

Tested Applications

Positive WB detected in	mouse testis tissue, HepG2 cells, HEK-293 cells, mouse liver tissue, human testis tissue
Positive IP detected in	mouse testis tissue
Positive IHC detected in	human heart tissue **Note: suggested antigen retrieval with TE buffer pH 9.0; () Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0***
Positive IF/ICC detected in	hTERT-RPE1 cells, MDCK cells

Recommended dilution

Application	Dilution
Western Blot (WB)	WB : 1:500-1:2000
Immunoprecipitation (IP)	IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
Immunohistochemistry (IHC)	IHC : 1:20-1:200
Immunofluorescence (IF)/ICC	IF/ICC : 1:20-1:200
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Published Applications

WB	See 1 publications below
IHC	See 1 publications below
IF	See 5 publications below

Product Information

22026-1-AP targets NPHP3 in WB, IHC, IF/ICC, IP, ELISA applications and shows reactivity with human, mouse, rat, canine samples.

Tested Reactivity	human, mouse, rat, canine
Cited Reactivity	human, mouse
Host / Isotype	Rabbit / IgG
Class	Polyclonal
Type	Antibody
Immunogen	CatNo: Ag16888 Product name: Recombinant human NPHP3 protein Source: e coli.-derived, PGEX-4T Tag: GST Domain: 1-131 aa of BC068082 Sequence: MGTASSLVSPAGGEVIEDTYGAGGGEACEIPVEVKPKARLLRNSFRRGAGAAAGAGPGSLPRGVGAGGLLGASFKSTGSSVPELEYAAAEYERLRKEYEIFRVSKNQELLSMGRREAKLDTENKRLRAELQ 相同性解析による交差性が予測される生物種
Full Name	nephronophthisis 3 (adolescent)
Calculated molecular weight	1330 aa, 151 kDa
Observed molecular weight	145-151 kDa
GenBank accession number	BC068082
Gene Symbol	NPHP3
Gene ID (NCBI)	27031
RRID	AB_2878975
Conjugate	Unconjugated
Form
Form	Liquid
Purification Method	Antigen affinity purification
UNIPROT ID	Q7Z494
Storage Buffer	PBS with 0.02% sodium azide and 50% glycerol{{ptg:BufferTemp}}7.3
Storage Conditions	Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage.

Protocols

Product Specific Protocols
IF protocol for NPHP3 antibody 22026-1-AP	Download protocol
IHC protocol for NPHP3 antibody 22026-1-AP	Download protocol
IP protocol for NPHP3 antibody 22026-1-AP	Download protocol
WB protocol for NPHP3 antibody 22026-1-AP	Download protocol

Standard Protocols
Click here to view our Standard Protocols

Publications

Species	Application	Title
mouse	IF	Nat Methods Genetically encoded calcium indicator illuminates calcium dynamics in primary cilia. Authors - Su Steven S View Article
human	IF	Am J Hum Genet ARL3 Mutations Cause Joubert Syndrome by Disrupting Ciliary Protein Composition. Authors - Sumaya Alkanderi View Article
human	IF	Hum Mol Genet Translational read-through of the RP2 Arg120stop mutation in patient iPSC-derived retinal pigment epithelial cells. Authors - Nele Schwarz View Article
mouse	IF	Int J Mol Sci Ciliary Proteins Repurposed by the Synaptic Ribbon: Trafficking Myristoylated Proteins at Rod Photoreceptor Synapses. Authors - Shweta Suiwal View Article
mouse	IF	Mol Biol Cell Interactions between TULP3 tubby domain and ARL13B amphipathic helix promote lipidated protein transport to cilia Authors - Vivek Reddy Palicharla View Article
		Methods Cell Biol Single-molecule imaging in the primary cilium Authors - Lucien E Weiss View Article
