CoraLite®594-conjugated ICAM-1 Polyclonal antibody

ICAM-1 Polyclonal Antibody for FC (Intra), IF

Host / Isotype

Rabbit / IgG

Reactivity

human

Applications

IF, FC (Intra)

Conjugate

CoraLite®594 Fluorescent Dye

Cat no : CL594-10831

Synonyms

BB2, CD54, ICAM 1, ICAM1, ICAM-1, P3.58

Validation Data Gallery

Applications:
  • IF Staining of human lung cancer using CL594-10831

    IF Staining of human lung cancer using CL594-10831

    Immunofluorescent analysis of (4% PFA) fixed human lung cancer tissue using CoraLite®594 ICAM-1 antibody (CL594-10831) at dilution of 1:200.

  • IF Staining of human lung cancer using CL594-10831

    IF Staining of human lung cancer using CL594-10831

    Immunofluorescent analysis of (4% PFA) fixed human lung cancer tissue using CoraLite®594 ICAM-1 antibody (CL594-10831) at dilution of 1:200.

  • FC experiment of Raji using CL594-10831

    FC experiment of Raji using CL594-10831

    1X10^6 Raji cells were intracellularly stained with 0.5 ug CoraLite®594 Anti-Human ICAM-1 (CL594-10831) (red), or 0.5 ug Control Antibody. Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

Tested Applications

Positive IF detected inhuman lung cancer tissue
Positive FC detected inRaji cells
For other applications, we recommend the unconjugated version of this antibody, 10831-1-AP

Recommended dilution

ApplicationDilution
Immunofluorescence (IF)IF : 1:50-1:500
Flow Cytometry (FC)FC : 0.50 ug per 10^6 cells in a 100 µl suspension
Sample-dependent, check data in validation data gallery

Product Information

CL594-10831 targets ICAM-1 in IF, FC (Intra) applications and shows reactivity with human samples.

Tested Reactivity human
Host / Isotype Rabbit / IgG
Class Polyclonal
Type Antibody
Immunogen ICAM-1 fusion protein Ag1188 相同性解析による交差性が予測される生物種
Full Name intercellular adhesion molecule 1
Calculated molecular weight 90 kDa
Observed molecular weight 85-95 kDa
GenBank accession numberBC015969
Gene symbol ICAM1
Gene ID (NCBI) 3383
RRIDAB_2919748
Conjugate CoraLite®594 Fluorescent Dye
Excitation/Emission maxima wavelengths588 nm / 604 nm
Form Liquid
Purification Method Antigen affinity purification
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

Background Information

Where is ICAM-1 expressed?

Intercellular Adhesion Molecule 1 (ICAM-1), also known as Cluster of Differentiation 54 (CD54) is a transmembrane glycoprotein constitutively expressed at low levels in endothelial cells, pericytes and on some lymphocytes and monocytes1. It is located at the cytoplasmic membrane, with a large extracellular region of mainly hydrophobic amino acids joined to a small transmembrane region and a cytoplasmic tail. It has a molecular weight of 75 to 115 kDa depending on the level of glycosylation.

 What is the function of ICAM-1?

ICAM-1 is important in both innate and adaptive immune responses as an adhesion molecule. Although it is constitutively expressed, in the presence of pro-inflammatory cytokines such as TNFα the endothelial cells are activated and upregulate expression of ICAM-12. In blood vessels lined with endothelial cells, leukocytes that are rolling over the surface are able to bind to ICAM-1 and transmigrate through the endothelial barrier and into the tissue. The initial binding of the leukocytes to ICAM-1 causes a Ca2+ release that initiates endothelial cell contraction and weakening of the intercellular tight junctions3, 4. This protein can be used as an indicator of endothelial activation and of vascular inflammation.

 What is the role of ICAM-1 in disease?

Beyond the role in the immune response, ICAM-1 has also been identified as the target of attachment for the human rhinovirus, the cause of the common cold. Binding of the virus to ICAM-1 causes the viral capsid to uncoat and leads to release of the genetic material5.

  1.  Hubbard, A. K. & Rothlein, R. Intercellular adhesion molecule-1 (ICAM-1) expression and cell signaling cascades. Free Radic. Biol. Med. 28, 1379-86 (2000).

  2. Long, E. O. ICAM-1: getting a grip on leukocyte adhesion. J. Immunol. 186, 5021-3 (2011).

  3. Lawson, C. & Wolf, S. ICAM-1 signaling in endothelial cells. (2009).

  4. Lyck, R. & Enzmann, G. The physiological roles of ICAM-1 and ICAM-2 in neutrophil migration into tissues. Curr. Opin. Hematol. 22, 53-59 (2015).

  5. Xing, L., Casasnovas, J. M. & Cheng, R. H. Structural analysis of human rhinovirus complexed with ICAM-1 reveals the dynamics of receptor-mediated virus uncoating. J. Virol. 77, 6101-7 (2003).


Protocols

Product Specific Protocols
IF protocol for CL594 ICAM-1 antibody CL594-10831Download protocol
FC protocol for CL594 ICAM-1 antibody CL594-10831Download protocol
Standard Protocols
Click here to view our Standard Protocols
